RICKENBACKER AND MADELEINE STRINGS ACOUSTIC GUITARS

THE BUILD PROCESS

BACK BRACING

This slide show follows roughly a step-by-step progression.

Slides advance every 10 seconds, but you can also go forward or backward using the arrows on each slide.

BACK BRACES ARE INDIVIDUALLY SHAPED BY HAND, GLUED INTO PLACE AND CLAMPED USING A "GO BAR" DECK. THE CENTER STRIP REINFORCES THE BACK JOINT.

A STACK OF 700C JUMBO BACKS WITH SHAPED BRACES GLUED INTO PLACE, WITH A BODY "HOOP" SET ON TOP. THE BACKS ARE NOT FLAT. BRACES ARE GLUED TO MAINTAIN A SPHERICAL RADIUS FOR STRENGTH AND PROJECTION.

DETAIL OF A 730L DREADNOUGHT BODY, WITH BACK GLUED INTO PLACE. NOTE NOTCHES IN THE TOP LINING TO CLEAR THE TOP BRACING.

VIEW OF A 730S BODY WITH THE BRACED BACK GLUED INTO PLACE. NECK HEEL AND TAIL BLOCKS CAN BE SEEN.

TO NEXT PAGE—TOP BRACING
